HC-4297 Pneumatic Oil Extractor

HC-4297 Pneumatic Oil Extractor

Popular model features everything a professional auto shop needs. Using compressed air, the venturi pump creates a vacuum in the steel tank. The easy-to-read vacuum gauge lets you know when you achieve the proper suction level. The HC-4297 is equipped with a large 16L collecting funnel, durable 90L capacity steel storage container, and 9L transparent bowl which gives the operator the option to check quantity and quality of oil prior to discharging into the tank below,includes 4 suction probes for fluid extraction. The bowl is heat resistant to a maximum of 60℃.This all-in-one fluid evacuator and self-evacuating oil drain gives you greater functional versatility when handling fluids in your shop.


  • Product Code: HC-4297 Pneumatic Oil Extractor
Tank capacity88L
Air inlet connection1/4”
Modular cylinder capacity11L
Collection bowl capacity20L
Air pressure for oil discharge0.7~1Bar
Vacuum degree-1~0Bar
Oil temperature range40-60℃
Suction Speed(max.)6.5Liter/m
N/G weight47/53kgs
Package dimension555*440*1565mm

The Portable HC-4297 Air-Operated Oil Extractor is a vacuum-charged unit that's ideal for extracting used oil and other fluids from almost any vehicle.

1.Vacuum&Explosion-proof integrated mechanism(Patented)
2. Modular Cylinder(Patented)
3. Tool tray
4. Support stand
5. Oil display scale
6. Waste oil collection
7. Resistant PVC wheel
8. Lift handlebar
9. Oil tank(Patented)
